Baryon
Equipped with built-in 4D SS-OCT technology and an integrated 4K 3D surgical system, Baryon offers unprecedented surgical precision and enhanced teaching guidance capabilities.
A 400 kHz high-speed swept-source OCT is integrated into the microscope system, providing ultra-widefield high-resolution intraoperative SS-OCT navigation and real-time 3D reconstruction imaging. The ultrawide and ultra-deep imaging and intraoperative measurement technology enhance the accuracy, safety, and comprehensiveness of surgeries.
The microscope's AAA optical technology and motorized wide-angle design, combined with an advanced automated control system, deliver a clear and deep visual field for ophthalmic surgeries, significantly improving surgical outcomes.
400KHz intraoperative SS-OCT：World’s first 400KHz SS-OCT built-in surgical microscope
4D intraoperative SS-OCT navigation：Real-time 3D OCT reconstruction imaging
4K 3D digital system
Intelligent measurement: Intraoperative real-time measurement technology
AAA optical system
Stereo coaxial illumination technology
Automatic control system
Baryon is not cleared by the CE/FDA.
Light source: | Xenon lamp |
Red reflex illumination: | Stereo coaxial illumination |
Working distance: | f = 200mm |
Surgeon's eyepiece: | Built-in electric inversion, adjustable tilt angle |
Zoom system: | Zoom ratio 1:6, stepless zoom |
Focusing range: | 70mm |
Assistant's eyepiece: | Built-in electric inversion, adjustable tilt angle |
Assistant's eyepiece adjustment method: | Independent focusing, stepless zoom, can be synchronized with the surgeon |
Fundus observation system: | Electric |
Stand system: | Electromagnetic lock stand |
Foot pedal: | 14 function keys |
Equipped with intraoperative swept-source OCT |  |
Equipped with 3D surgical system | |
4D holographic OCT function (optional) | |
